minio 集群搭建-白红宇

minio 集群搭建

阅读量：5998 次

发布时间：2019-06-20

本文共 2741 字，大约阅读时间需要 9 分钟。

具体实际的取舍可以参考官方文档，我使用的是4 node 4 driver 模式

环境机器说明

192.168.31.2 192.168.31.3 192.168.31.4 192.168.31.5每台机器单独挂在4块盘  data1 data2 data3 data4minio 安装包参考github 网站

参考图

启动&&运行

配置key(实际可以直接配置到profile中)

export MINIO_ACCESS_KEY=

      export MINIO_SECRET_KEY=

启动(每台机器执行)

/usr/local/bin/minio server http://192.168.31.2/data1 http://192.168.31.2/data2 \               http://192.168.31.2/data3 http://192.168.31.2/data4 \               http://192.168.31.3/data1 http://192.168.31.3/data2 \               http://192.168.31.3/data3 http://192.168.31.3/data4 \               http://192.168.31.4/data1 http://192.168.31.4/data2 \               http://192.168.31.4/data3 http://192.168.31.4/data4 \               http://192.168.31.5/data1 http://192.168.31.5/data2 \               http://192.168.31.5/data3  http://192.168.31.5/data4等待片刻，节点加入成功，并会格式化磁盘

配置nginx 支持lb

我使用了lvs nginx 是在realserver 上，并使用了dr 模式

upstream minio {      server 192.168.31.2:9000 weight=10 max_fails=2 fail_timeout=30s;       server 192.168.31.3:9000 weight=10 max_fails=2 fail_timeout=30s;       server 192.168.31.4:9000 weight=10 max_fails=2 fail_timeout=30s;       server 192.168.31.5:9000 weight=10 max_fails=2 fail_timeout=30s;    }   server {    listen 9000;        server_name localhost;        charset utf-8;        default_type text/html;        location /{           proxy_set_header Host $http_host;                proxy_set_header X-Forwarded-For $remote_addr;            client_body_buffer_size 10M;                client_max_body_size 10G;                   proxy_buffers 1024 4k;                proxy_read_timeout 300;                proxy_next_upstream error timeout http_404;             proxy_pass http://minio;        }     }

访问测试

说明

实际使用可能需要使用systemd 进行管理，官方提供了脚本

参考脚本

[Unit]Description=MinioDocumentation=https://docs.minio.ioWants=network-online.targetAfter=network-online.targetAssertFileIsExecutable=/usr/local/bin/minio[Service]WorkingDirectory=/usr/localUser=minio-userGroup=minio-userPermissionsStartOnly=trueEnvironmentFile=-/etc/default/minioExecStartPre=/bin/bash -c "[ -n \"${MINIO_VOLUMES}\" ] || echo \"Variable MINIO_VOLUMES not set in /etc/defaults/minio\""ExecStart=/usr/local/bin/minio server $MINIO_OPTS $MINIO_VOLUMES# Let systemd restart this service only if it has ended with the clean exit code or signal.Restart=on-successStandardOutput=journalStandardError=inherit# Specifies the maximum file descriptor number that can be opened by this processLimitNOFILE=65536# Disable timeout logic and wait until process is stoppedTimeoutStopSec=0# SIGTERM signal is used to stop MinioKillSignal=SIGTERMSendSIGKILL=noSuccessExitStatus=0[Install]WantedBy=multi-user.target# Built for ${project.name}-${project.version} (${project.name})
